Capabilities

• Multiple inputs and outputs
• Up to 10 digital inputs
• Up to 10 digital outputs
• Up to 6 analog inputs
• Automatic protection against inrush currents and detection of supply voltage level
• Automatic and continuous management of GPRS connection
• Stable and reliable TCP/IP connection in GPRS network
• High GPS sensitivity up to 160DBM
• Internal offline data storage up to 32MB and automatic resending when connected
• Built-in LI-ION backup battery
• The software development environment and communication port with server
• Smart features to reduce GPRS costs
• Remote programming through GPRS, SMS
• Secure and encrypted communication protocol
• The ability to UPDATE the sent protocol every once in a while to prevent data disclosure
• It has USB port to connect with TABLET, CAR PC, PC
• It has standard HID protocol to communicate with the processor
• The ability to add navigation direction and taximeter
• Receive settings by SERVER, SMS and locally
• Warning when starting the car or moving from the parking place (PARK FENCING)
• Warning of entering and leaving the specified area (GEO FENCING)
• Update FIRMWARE device software
• Connecting to all types of online and offline payment POSs
• With visual indicators to check the performance of the device
• Remote control of DIGITAL inputs and outputs
• Smart antenna short circuit detection
• Ability to listen remotely through the internal microphone of the device
• Two-way audio communication with external microphone and car speakers
• Ability to add RS485 port to control electronic devices with RS232 port
• Stylish aluminum box with suitable dimensions and weight and high physical durability

Applications

Tracking of trucks and containers, advanced applications of vehicle tracking, intelligent systems, fleet management, recovery of stolen vehicles

Features of AVL in simple language

Park Fencing

According to several parameters that can be adjusted by the user, this system intelligently detects the parking of the car, if the car leaves the parking place in any way, either by the driver or by the cranes that carry the car, etc., it warns the user. data and starts tracking the car.

Listening and two-way communication with the driver

Using its internal simcard system, this device allows the user to fully listen to the sounds inside the car during the call, or to talk to the driver through the car’s speakers if desired.

Geo Fencing

By using this technology, location limits are defined for the driver, and these limits are defined in two ways: no entry or no exit. If the driver enters the no-entry zone, the system gives the necessary warnings on the server, or if the driver leaves the no-exit zone, the system notices this exit and warns the user. These ranges can be defined by the user and are unlimited in number. For example, city limits are defined as no-exit limits for taxi or city bus drivers.

Command to stop the car at the time of theft

If the user realizes that his car has been stolen, by sending an SMS to the system, he announces the theft of the car, and the moment the car stops moving, the device inside the car will be turned off and the doors will be locked. and the car is prevented from starting again, the car will stop until the user reaches the car’s location and send the retrieve order to the device.

Data transmission security protocol

One of the most important issues in this system is secure data transmission from the device to the server. This data transmission is done through the Internet (GPRS) or through SMS (GSM). Therefore, in order to prevent penetration into the system and to identify the location of the vehicle, all the information sent is first encrypted using the Harding algorithm and then re-encrypted with another encryption algorithm such as AES-128 or AES-256. This makes the system impenetrable. It is worth mentioning that the password key is specified only by the user’s admin account and in order to change the key, In addition to basic information and system access level, it is also necessary to know the previous key.

Information about the condition of the car

This device has a large number of digital and analog inputs, which can be used to add desired types of sensors to the system. These sensors can be selected from the following items as needed:

• Crash detection sensor
• Presence sensor in the car
• Emergency alarm sensor
• Fuel level detection sensor
• Temperature and humidity sensor (suitable for machines carrying food and chemical products)
• Impact sensor

etc…
This device has a fully intelligent alarm detection system, which can be used to generate different types of alarms.

Smart data collection

This system intelligently samples displacement, speed and time using several parameters. This has caused the amount of information to be sent to be very low, and as a result, the cost of telecommunications for using this system is at its lowest.

Internal memory

One of the important issues in this system is to save information when the device is disconnected from the server. This device has an internal memory with variable volumes, and with the amount of memory installed on the device by default, more than 1,000,000 points can be stored in it.

Navigation capability

Using the USB port of this device, it can be connected to a tablet and with the software that is installed on it, the device can also act as a navigator. In other words, determining the optimal route, guiding at intersections and announcing the amount of obstacles remaining until the destination, are other capabilities of this device.

System modules

One of the important features of this device is the use of high-quality modules. The main modules of this device are from the German Simence and Swiss Ublox brands, and the processors of this device are also from NXP company, and the rest of its elements are selected from the military type.
